The wireless fire alarm and fire linkage control panel TC5126W is with wall-mounted structure and modular design. The main components are as following.
1.Main control module
The main control board is responsible for analyzing and processing the information data transmitted by other components in the system, and according to the data analysis results, commanding other components in the system to execute corresponding commands, such as control speaker voice alarm, etc.
2.Display module
The display component provides the main output interface of alarm information, as well as the daily maintenance and query interface.
3.Key module
Matrix buttons are used in the control panel, which is very convenient for users to set up and maintain the system.
4.Power module
The power supply module supplies power for the whole system equipment, and provides power fault signals such as main power fault, standby power fault and standby power undervoltage, and has good anti-interference ability.
The wireless alarm and linkage control system has the same functions of alarm and linkages as traditional addressable alarm and linkage control systems.
5.Wireless 470 module
The 470MHzFSK coded bidirectional communication can communicate with 32 wireless devices.
6.Loop control panel
This control panel can be connected with 18 intelligent loop control panels, which has less wiring and high reliability. Each start/stop key on the manual fire control startup panel can be associated with any bus equipment connected to the system by definition, and complete the start/stop control of the bus linkage equipment, thus thoroughly solving the inherent problems of engineering wiring, equipment configuration and installation and debugging of the alarm linkage integrated system.
7.Direct control panel
This control panel can be equipped with 6-way three-wire direct control panel, and has the functions of detecting open circuit and short circuit of output line, which can guarantee the reliability of the control module itself and its connection with important equipment to the maximum extent.
Through wireless and multi-loop control, it can not only complete the functions of alarm and start/stop control of general fire-protection equipment, but also realize the control of important fire-protection equipment.
The loop control panel has 18 manual fire starting points, and each starting point has a key, two indicators and a label. Among them, the key is the start/stop control key. If the control key of a certain unit is pressed, the control command will be sent out. When the start-up state of the equipment is received, the command light of the unit will light up (red). If the controlled equipment starts and sends out a feedback signal, the answer indicator will light up (red). The user can write the device name corresponding to each key on the device label, and then fix it on the manual disk together with the diaphragm.
Compared with traditional addressable alarm and linkage control systems, wireless alarm and linkage systems do not require cable laying. Wireless smoke detectors, wireless heat detectors, wireless MCPs, wireless gas detectors, and many other front-end alarm devices can be connected to the alarm control panel through simple setting buttons.
The TC wireless fire alarm system can be used with other brand wired fire alarm system as well.
Through wireless transceivers, the wireless smoke detectors, heat detectors, wireless manual call points can be connected to traditional wired fire alarm circuits.
So, the wireless fire alarm system easily solved the problem of fire protection renovation projects of adding extra fire detectors needs.
Wireless fire alarm and fire linkage control system
